Machinery power supply box with four-pole circuit breaker C25A, type F socket + Rescue Device
On order
Need advice?
Call us on +33 (0)9 69 32 22 57 for product advice or help to finalize your purchase. Free call.
Product description
Composition:
•1 enclosure 2 x12 modules 250x97x350mm
- (x1) 4-pole circuit breaker 25 A, 400 Vac, C curve
- (x2) 16 A circuit breaker, 230 Vac, 30 mA residual current
- (x2) 6 A circuit breaker, 230 Vac, C curve
- (x2) 10 A circuit breaker, 230 Vac, C curve
- (x1) latching relay 16 A, 250 Vac
- (x1) power socket, 250 Vac, 16 A, type F
- (x1) auxiliary contact
•Mounting accessories
- (x1) circuit breaker lockout device
Additional Information:
•lockable with a padlock (not supplied)
Standards Compliance:
- EN IEC 61439
- EN81-20
- EN 60898
- NF P82-230
More Information
| Weight | 2.66 kg |
|---|---|
| Longueur colis | 25.00 cm |
| Largeur colis | 9.70 cm |
| Profondeur colis | 35.00 cm |
| Eco Contribution | €0.00 |
| Type | Simplex |
| Amperage | 25 A |
Composition:
•1 enclosure 2 x12 modules 250x97x350mm
- (x1) 4-pole circuit breaker 25 A, 400 Vac, C curve
- (x2) 16 A circuit breaker, 230 Vac, 30 mA residual current
- (x2) 6 A circuit breaker, 230 Vac, C curve
- (x2) 10 A circuit breaker, 230 Vac, C curve
- (x1) latching relay 16 A, 250 Vac
- (x1) power socket, 250 Vac, 16 A, type F
- (x1) auxiliary contact
•Mounting accessories
- (x1) circuit breaker lockout device
Additional Information:
•lockable with a padlock (not supplied)
Standards Compliance:
- EN IEC 61439
- EN81-20
- EN 60898
- NF P82-230
| Weight | 2.66 kg |
|---|---|
| Longueur colis | 25.00 cm |
| Largeur colis | 9.70 cm |
| Profondeur colis | 35.00 cm |
| Eco Contribution | €0.00 |
| Type | Simplex |
| Amperage | 25 A |
