Machinery power supply box, 4-pole MCB D10A, type F socket+Rescue Device
On order
DTU Simplex power supply enclosure for elevator machine room, fitted with a D-curve 10A four-pole circuit breaker. Wired with a type F (Schuko) socket outlet, suitable for installations outside France (continental Europe, export markets). The D-curve 10A tripping characteristic offers high tolerance to start-up current peaks, recommended for high-inertia motors. Includes an auxiliary contact for connecting a Rescue Device, ensuring passenger safety in the event of a power failure.
Need advice?
Call us on +33 (0)9 69 32 22 57 for product advice or help to finalize your purchase. Free call.
Product description
Composition:
•1 enclosure 2 x12 modules 250x97x350mm
- (x1) 4-pole circuit breaker 10 A,400 Vac,D curve
- (x2) 16 A circuit breaker,230 Vac,30 mA residual current
- (x2) 6 A circuit breaker,230 Vac,C curve
- (x2) 10 A circuit breaker,230 Vac,C curve
- (x1) latching relay 16 A,250 Vac
- (x1) power socket,250 Vac,16 A,type F
- (x1) auxiliary contact
•Mounting accessories
- (x1) circuit breaker lockout device
Additional Information:
•lockable , a padlock (not supplied)
Standards Compliance:
- EN IEC 61439
- EN81-20
- EN 60898
- NF P82-230
More Information
| Weight | 2.66 kg |
|---|---|
| Longueur colis | 25.00 cm |
| Largeur colis | 9.70 cm |
| Profondeur colis | 35.00 cm |
| Eco Contribution | €0.00 |
| Type | Simplex |
| Amperage | 10 A |
Composition:
•1 enclosure 2 x12 modules 250x97x350mm
- (x1) 4-pole circuit breaker 10 A,400 Vac,D curve
- (x2) 16 A circuit breaker,230 Vac,30 mA residual current
- (x2) 6 A circuit breaker,230 Vac,C curve
- (x2) 10 A circuit breaker,230 Vac,C curve
- (x1) latching relay 16 A,250 Vac
- (x1) power socket,250 Vac,16 A,type F
- (x1) auxiliary contact
•Mounting accessories
- (x1) circuit breaker lockout device
Additional Information:
•lockable , a padlock (not supplied)
Standards Compliance:
- EN IEC 61439
- EN81-20
- EN 60898
- NF P82-230
| Weight | 2.66 kg |
|---|---|
| Longueur colis | 25.00 cm |
| Largeur colis | 9.70 cm |
| Profondeur colis | 35.00 cm |
| Eco Contribution | €0.00 |
| Type | Simplex |
| Amperage | 10 A |
