Machinery power supply box with four-pole circuit breaker D25A , type F socket
On order
Need advice?
Call us on +33 (0)9 69 32 22 57 for product advice or help to finalize your purchase. Free call.
Product description
Composition:
•1 enclosure 2 x12 modules 250x97x350mm
- (x1) 4-pole circuit breaker 25 A, 400 Vac, D curve
- (x2) 16 A circuit breaker, 230 Vac, 30 mA residual current
- (x2) 6 A circuit breaker, 230 Vac, C curve
- (x2) 10 A circuit breaker, 230 Vac, C curve
- (x1) latching relay 16 A, 250 Vac
- (x1) power socket, 250 Vac, 16 A, type F
•Mounting accessories
- (x1) circuit breaker lockout device
Additional Information:
•lockable with a padlock (not supplied)
Standards Compliance:
- EN IEC 61439
- EN81-20
- EN 60898
- NF P82-230
More Information
| Weight | 2.60 kgs |
|---|---|
| Longueur colis | 36.00 CM |
| Largeur colis | 26.00 CM |
| Profondeur colis | 11.50 CM |
| Eco Contribution | €0.00 |
