VERSO Controller machine room less (MRL)

Additional informations:

• installation without machine room
• dimensions: 1980 x 370 x 250 mm
• Rescue device management included
• according to the standards:
   - EN 81-20: Siren function and buzzer integrated in VERSO car roof unit + Emergency battery integrated
   - EN 81-21: Reduced clearances management by overspeed governor and double way safety gears or by upper stops +
                      Lock contacts managed by electronics (SIL 3)
   - EN 81-70: Integrated voice synthesis
   - UCM - Uncontrolled Car Movement management is integrated: Brake on low speed shaft / Locking of the overspeed governor (without Re-leveling )

Technical characteristics

• Control:
   - Automatic push button / Non-directional collective / Down collective / Full collective
   - 30 levels bus or wired (7 basements)
   - 1 or 2 side(s) of service (elapsing, opposite ou square)
   - Simplex / Duplex / Triplex / Quadruplex
   - Wired or BUS landing

• Motorisation: synchronous or asynchronous

• Power :
  - 4 to 11 kW
  - Three phase 220 V or 380 V Power supply

• Selection:
   - Safety optronic sensor SIL2
   - Stopping accuracy: 1.2 mm
   - Management between short levels: 30 mm
   - Toe-guards control
   - Automatic travel curve calculation
   - Maximum speed: 1.6 m/s

• Other functions :
   - Digital code by the car operating panel (COP)
   - Autonomous door / Box with opening/closing orders / Three phases 380 V
   - Screen locking
   - Electro cams and brakes tensions from 40 to 120 VCC / Brake 220 V
